OH85F (Outdoor)

A powerful all-inclusive outdoor signage solution with an embedded power box


  • All-in-one solution complete with an embedded power box, along with an ultra-slim depth of 85mm
  • An optimum level of endurance equivalent to IK10 and extra durability with IP56 Ingress Protection
  • A filterless self-cooling system enabling easy maintenance and reduced TCO
  • Excellent visibility under direct sunlight through 2,500-nit high brightness and anti-reflection glass


Diagonal Size Class 85
Measured 84.5″ / 214cm
Type 60Hz D-LED Local Dim. BLU
Resolution  3840×2160 (16:9)
Pixel Pitch(mm) 0.488 x 0.488
Active Display Area(mm) 1872(H) x 1053(V)
Brightness(Typ.) 2,500 cd/m2
Contrast Ratio 3000:1
Viewing Angle(H/V) 178/178
Response Time(G-to-G) 8ms
Display Colors 10 bit – 1.07B
Color Gamut 72%

Mechanical Spec

Dimension (mm) Set 2004 x 1185 x 120
Package 2175 x 1383 x 495
Weight (kg) Set 163kg
Package 211kg
Mounting Hole 1000 x 1118.4 (M8 x 8Hole)
Protection Glass Yes (5T Tempered Glass)
Stand Type N/A
Bezel Width (mm) 62 / 62 / 62 / 62 mm


      Operating Temperature -30℃~ 50℃
Humidity 10~80%
