QM43R

Display any content in ultra-high definition with incredibly rich color on slim, efficient signage.

Description

Display any content in ultra-high definition with incredibly rich color on slim, efficient signage.

  • Engage customers with lifelike images through ultra high-definition resolution
  • Deliver UHD-level picture quality even with lower resolution content through innovative UHD upscaling technology and unique picture-enhancing features
  • Dynamic Crystal Color allows viewers to enjoy a wider spectrum of colors, up to one billion shades

Panel

Diagonal Size Class 43
Measured 42.5
Type Edge LED BLU
Resolution UHD (3840 x 2160)
Pixel Pitch (mm) 0.2451 x 0.2451
Active Display Area 941.184 (H) x 529.416 (V)
Brightness(Typ.) 500
Contrast Ratio (Typ.) 4000:1
Viewing Angle(H/V) 178/178
Response Time (G to G) 8ms(Typ.)
Display Colors 16.7M(True Display)
1.07B(Ditherd 10bit)
Color Gamut 92% (DCI-P3, CIE 1976)
Operation Hour 24/7
Haze 44%

Mechanical Spec

Dimension(mm) Set 967.5 x 557.7 x 48.3
Package 1095 x 676 x 151
Weight (kg) Set 10
Package 13.3
VESA Mount 200 X 200
Protection Glass N/A
Stand Type Foot Stand (Optional)
Bezel Width (Top/Side/Bot) (mm) 9.2mm(U/L/R), 11.2mm(B)

Operations

Operating Temperature 0℃~ 40℃
Humidity 10~80%
